ELAR 180 PAR RGBWA

Features

High Power Outdoor IP65 Rated RGBWA LED Par
(60) 3W RGBAW LEDs (12 per color)
9° Beam 22°Field Angles with Standard 10° Lens Kits Available
Smooth Color Mixing
Internal Color Macros
Auto and Manual Control
Flicker Free Operation for TV and FILM

Resources

Specifications Sheet

User Manual

Photometric Test Report

Photometric IES File

DMX Traits

Dimensional Drawing

CAD Drawing

Specifications

SOURCE
(60) 3W RGBAW LEDs (12 per color)
100,000 Hour Average LED Life*
*May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.



EFFECTS
9° Beam - 22° Field Angles
Internal Color Macros

COLOR
RGBAW

CONTROL / CONNECTIONS
4 DMX Channel Modes (10 Total Channels)
4 Button Control Panel and LCD Menu Display
IP Rated 3pin DMX and power In/Out

SIZE / WEIGHT
Length: 8.9” (226mm)
Width: 10.5” (267mm)
Vertical Height: 9.1” (232mm)
Weight: 16.5 lbs. (7.5kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
185W Max Power Consumption
Multiple Unit Power Linking


APPROVALS / RATINGS
CE | cETLus | IP65



SKU# EAR602
ELAR 180 PAR RGBAW WH - same as above WHITE housing



Specifications and documentation subject to change without notice.
