CUEPIX Blinder WW2

Features

 High Power Long Life Warm White COB LEDs
 60° Beam Angle / 80° Field Angle
 Individual Control of Each COB Module
 Dimming: 0% - 100% of Each COB Module
 RDM (Remote Device Management)
 Flicker FREE Operation for TV and FILM
 Stand Alone Operation with Master/Slave Function
 Integrated Rigging Bracket

Resources

Specifications Sheet

Photometric IES File

User Manual

Vectorworks Symbol

Photometric Test Report

CAD Drawing

Dimensional Drawing

Photometric Data

DMX Traits

Specifications

SOURCE
(2) 100W Warm White 3,200K COB LEDs
100,000 Hour Average Life*
*LED Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

PHOTOMETRIC DATA
5900 Max LUX (548 fc) @1M (Full On)

EFFECTS
Strobe
Variable / Selectable Dimming Curves

CONTROL / CONNECTIONS
4 DMX Channel Modes (1 / 2 / 3 / 4)
4 Button Control Panel and LCD Menu Display
3pin and 5pin DMX In/Out
RDM* (Remote Device Management)  *Software Version 1.13 or Higher
powerCON Power In/Out

SIZE / WEIGHT
Length: 18.8” (478 mm)
Width: 7.1” (181.2 mm)
Horizontal Height: 10.2” (259.4 mm)
Weight: 11.2 lbs. (5.1 kg)

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
229W Max Power Consumption
-14°F to 113°F (-10°C to 45°C)

APPROVALS / RATINGS
CE | cETLus | IP20

INCLUDED ACCESSORIES
(1) powerCON Cable



Specifications and documentation subject to change without notice.
