ELAR QUAD PANEL
Features
- 16 X 10W Cree Quad LED
- No colored shadows and perfect color mixing
- Single Pixel control mode
- 12170 Lux @ 2,5m
- 12° beam angle, 21° field angle
- IP65 die cast aluminum body
- Flicker free operation for television and film
- Color LCD Display
- USITT DMX 512
- 4/5/8/10/8_2/16_4/64 Channel operation modes
- Built In Color Macros, Auto & Manual control
- Holds last state when power off
- 0-100% Dimming
- Strobe effect (1-18 flashes per second)
- 3-pin XLR in/out
- Power in/out linkable
- Electronic Switching Power Supply
- Power Consumption: 290 watts
- 100-240V AC, 50/60Hz (Multi-voltage)
- Dimensions (LxWxH): 19.7 x 4.7 x 19.7 inches
- Weight: 42lbs
- cETLus Approved
Resources
Specification information
Guides/ Manuals
PHOTOMETRIC DATA
DMX/ RDM Traits
Drawings
Related Categories
Specifications
- 16 X 10W Cree Quad LED
- No colored shadows and perfect color mixing
- Single Pixel control mode
- 12170 Lux @ 2,5m
- 12° beam angle, 21° field angle
- IP65 die cast aluminum body
- Flicker free operation for television and film
- Color LCD Display
- USITT DMX 512
- 4/5/8/10/8_2/16_4/64 Channel operation modes
- Built In Color Macros, Auto & Manual control
- Holds last state when power off
- 0-100% Dimming
- Strobe effect (1-18 flashes per second)
- 3-pin XLR in/out
- Power in/out linkable
- Electronic Switching Power Supply
- Power Consumption: 290 watts
- 100-240V AC, 50/60Hz (Multi-voltage)
- Dimensions (LxWxH): 19.7 x 4.7 x 19.7 inches
- Weight: 42lbs
- CE | cETLus | IP65
