DESIGN LED 12 BRICK II
Design LED 12 Brick II is a professional-grade lighting solution. Compact LED High Power Pixel / Wall Wash Brick? • Built-in Power Supply and DMX 512 Control • cETLus and CE approved ? Compact LED High Power Pixel / Wall Wash Brick? (rated at 100,000 Hours)?#160; • Built-in Power Supply and DMX 512 Control • cETLus and CE approved ?#160;?#160;.
DESIGN LED 12 BRICK II
Compact LED High Power Pixel / Wall Wash Brick? 12 x 1W Luxeon I LED's - (4 Ea. R, G, B)? ? Seamless RGB color mixing? ? Infinite Color possibilities? ? Compact Design? ? 44° Beam Angle Flicker Free operation for TV? ? 480 lumens @ 1m per unit @ FULL? ? 1340 lumens @ 1m per kit of 4 units @ FULL? ? Long Life L.E.D. (rated at 100,000 Hours)? Built-in Power Supply and DMX 512 Control cETLus and CE approved ? ?
- Compact LED High Power Pixel / Wall Wash Brick?
- 12 x 1W Luxeon I LED's - (4 Ea. R, G, B)? ?
- Seamless RGB color mixing? ?
- Infinite Color possibilities? ?
- Compact Design? ?
- 44° Beam Angle
- Flicker Free operation for TV? ?
- 480 lumens @ 1m per unit @ FULL? ?
- 1340 lumens @ 1m per kit of 4 units @ FULL? ?
- Long Life L.E.D. (rated at 100,000 Hours)?
- Built-in Power Supply and DMX 512 Control
- cETLus and CE approved ? ?
Specifications
• USITT-DMX 512??
• 3, 4, 12 OR 15CH operation modes??
• LED Menu Display control 4 button
• Built in color macros / chases
• Stand alone or Primary/Secondary function
• Pixel control in 12 or 15 ch mode??
• 3 amp; 5 pin XLR in/out??
• IEC Power in/out??CONTROL FEATURES??
• Primary/Secondary auto program and music trigger ??
• 8 built-in programs with Speed control??
• Strobe effect (0-18 flashed per second)??
• Control each L.E.D. independently??
• 0-100% Dimming??POWER SUPPLY??
• 100-240V AC, 50/60Hz??
• On/Off Power switch??
• Power Consumption: 30 watts??RIGGING??
• Split Yoke Design / Hanging or Floor
• Mounting bracket and safety I-hook installed ?
• Optional bracket kit for multiple units (DLEDKIT)??
DIMENSIONS amp; WEIGHT:??
• 16.3”L x 4.5”W x 3.2”H??
• 5 lbs. (7.7lbs packaged)
