PIXEL DRIVE 8

Alkalite L.E.D Controller

• This Control Pack is designed to be used with the Octopod 30 and the Quadra LED Lighting Systems. The Control Pack comes with 9 Stand alone programs with both speed and fade control, or can be used via DMX-512. The Controller gives you 6 DMX Channnels DMX CHANNELS
• Ch1: Color Macros / Speed
• Ch2: Red 0-100% Dimming / Fade
• Ch3: Green 0-100% Dimming
• Ch4: Blue 0-100% Dimming
• Ch5: Strobe 1-29fps
• Ch6: Pre programmed Chases In the 6 Channel DMX mode 1 each drives all 8 units at once. For individual control the Pixel Drive 8 allows for 6,12,24 and 48 channel mode. Allowing you to control each unit individually. CONTROL FEATURES
• USITT DMX-512
• 4 Channel Modes
• 6,12,24 or 48 DMX Channels
• 4 Digit Digital LED Display
• Self Test & Stand Alone settings
• 3 pin XLR serial input/output
• Sound Active mode. (Sensitivy Knob)
• PreProgrammed Chases via DMX DMX CHANNELS
• Ch1: Color Macros / Speed
• Ch2: Red 0-100% Dimming / Fade
• Ch3: Green 0-100% Dimming
• Ch4: Blue 0-100% Dimming
• Ch5: Strobe 1-29fps
• Ch6: Pre programmed Chases DIMENSIONS & WEIGHT
• 12"x6"x3"
• 6.62 lbs POWER SUPPLY
• Magnetic Ballast
• 120V 60Hz
• Fuse: 2 Amp
• Power Draw: 95 Watts
