PROTEUS BRUTUS WMG HW


1200W Peak Field LED IP65 Wash FX Fixture

PROTEUS BRUTUS WMG HW is a professional-grade lighting solution. The PROTEUS BRUTUS WMG HW™ is an extremely bright IP65 rated LED Wash FX fixture offering high intensity wash and effects qualities in White Marine Grade (WMG) coating and Hard-Wire connections. Providing up to 75.000 lumens from its custom designed 1200W Peak Field LED engine the Proteus Brutus is the ideal fixture for any outdoor application requiring superior output, bright and powerful wash, quiet operation as well as stunning colors and effects.

UPC: 810008264096SKU: PRB312

PROTEUS BRUTUS WMG HW

The PROTEUS BRUTUS WMG HW™ is an extremely bright IP65 rated LED Wash FX fixture offering high intensity wash and effects qualities in White Marine Grade (WMG) coating and Hard-Wire connections. Providing up to 75.000 lumens from its custom designed 1200W Peak Field LED engine the Proteus Brutus is the ideal fixture for any outdoor application requiring superior output, bright and powerful wash, quiet operation as well as stunning colors and effects. Proteus Brutus provides the designer a comprehensive FX package with 6 rotating glass gobos, animation wheel, frost and a high-speed Iris. Its optional indexable framing system provides full blackout shutter cuts for precise beam shape control. With a fast zoom range from 4.5° to 45° and an impressive 220mm front lens the Proteus Brutus has the power to cut through at great distances in any outdoor concert, special events and with its fully dust and waterproof design it is an ideal fixture for theme parks and cruise ships or any application that benefits from its sealed IP65 housing. The PROTEUS BRUTUS WMG HW fixture ships in a cardboard box with a custom fitted polyurethane foam FIL (Foam In Lay) insert. This foam insert easily fits into a custom sized flight case (not included), and provides enhanced impact protection during transport. Key FeaturesHigh Efficiency 1200W 6,500K Peak Field LED Engine Up to 75.000 Total Lumen Fixture OutputCMY Color Mixing and Variable CTO 6 Position Color Wheel, High CRI, UV filterComplete FX System featuring Rotating Gobos, Animation, Iris, FrostOptional Full Blackout Framing ModuleWide Zoom Range from 4.5° to 45° / Large 220mm (8.7”) Front ApertureWhite Marine Grade Housing Direct Hard Wire Connections FIL (Foam In Lay) Polyurethane Foam Packaging Included; .

Specifications

SOURCE

1200W 6,500K Bright White LED Engine

30,000 Hour Average LED Life*

*May vary depending on several factors including but not limited to:

Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.


PHOTOMETRIC DATA

75,000 Total Lumen Output

CRI 70+ (82+ with HCRI Filter)

2:1 Peak Field

Zoom Range 4.5° - 45°

Beam Angle 4.4° - 39.4°

Field Angle 6.8° - 49.7°


EFFECTS

Motorized Zoom (220mm / 8.7 in Front Aperture)

Full 360° Bi-Directional Animation Wheel

Variable Frost Filter

Motorized Iris with Variable Pulse Effects

Variable 16-bit Dimming Curve Modes

High Speed Electronic Shutter and Strobe

DMX Controllable LED Refresh Rate

Pan Angle: 540°/630°

Tilt Angle: 266°


COLOR

CMY Color Mixing

Linear CTO Color Correction

6 Dichroic Colors including High CRI Filter and UV


GOBOS

6 Rotating / Indexing Interchangeable Beam Shaping + FX Gobos


OPTIONAL FRAMING MODULE

4 Rotating Full Blackout Framing Blades

+/-45° Framing Indexing


CONTROL / CONNECTIONS

4 DMX Channel Modes (25 / 36 / 34 / 56)

16-bit Pan, Tilt and Dimming Control

Motorized Focus

DMX, RDM, Art-NET, sACN Protocol Support

(6) Button Touch Control Panel

Full Color 180° Reversible LCD Menu Display

Hibernation Mode (Power Save)

Power Input Cable 5m

DMX In/Out Cable 5m

With Wired Digital Communication Network


SIZE / WEIGHT

Length: 25.3 in (643.6mm)

Width: 18.0 in (456.9mm)

Height: 34.2 in (869mm)

Weight: 104.1 lbs. (47.2kg)


ELECTRICAL

AC 120-240V 50/60Hz

Max Power Consumption 1,700W

14°F to 113°F (-20°C to 45°C)


APPROVALS / RATINGS

CE | cETLus | IP65 | UKCA


Specifications and documentation subject to change without notice.
