Design LED 12 Brick II
Design LED 12 Brick II
Discontinued
SKU# DLED12 BRICK II
Compact LED High Power Pixel / Wall Wash Brick? • 12 x 1W Luxeon I LED’s - (4 Ea. R, G, B)? ? • Seamless RGB color mixing? ? • Infinite Color possibilities? ? • Compact Design? ? • 44º Beam Angle • Flicker Free operation for TV? ? • 480 lumens @ 1m per unit @ FULL? ? • 1340 lumens @ 1m per kit of 4 units @ FULL? ? • Long Life L.E.D. (rated at 100,000 Hours)? • Built-in Power Supply and DMX 512 Control • cETLus and CE approved ? ?
Features
Compact LED High Power Pixel / Wall Wash Brick?
• 12 x 1W Luxeon I LED’s - (4 Ea. R, G, B)? ?
• Seamless RGB color mixing? ?
• Infinite Color possibilities? ?
• Compact Design? ?
• 44º Beam Angle
• Flicker Free operation for TV? ?
• 480 lumens @ 1m per unit @ FULL? ?
• 1340 lumens @ 1m per kit of 4 units @ FULL? ?
• Long Life L.E.D. (rated at 100,000 Hours)?
• Built-in Power Supply and DMX 512 Control
• cETLus and CE approved ? ?
• 12 x 1W Luxeon I LED’s - (4 Ea. R, G, B)? ?
• Seamless RGB color mixing? ?
• Infinite Color possibilities? ?
• Compact Design? ?
• 44º Beam Angle
• Flicker Free operation for TV? ?
• 480 lumens @ 1m per unit @ FULL? ?
• 1340 lumens @ 1m per kit of 4 units @ FULL? ?
• Long Life L.E.D. (rated at 100,000 Hours)?
• Built-in Power Supply and DMX 512 Control
• cETLus and CE approved ? ?
Resources
Guides/ Manuals
Related Categories
Specifications
CONTROL SPECIFICATIONS? ?
• USITT-DMX 512? ?
• 3, 4, 12 OR 15CH operation modes? ?
• LED Menu Display control 4 button
• Built in color macros / chases
• Stand alone or Primary/Secondary function
• Pixel control in 12 or 15 ch mode? ?
• 3 & 5 pin XLR in/out? ?
• IEC Power in/out? ? CONTROL FEATURES? ?
• Primary/Secondary auto program and music trigger ? ?
• 8 built-in programs with Speed control? ?
• Strobe effect (0-18 flashed per second)? ?
• Control each L.E.D. independently? ?
• 0-100% Dimming? ? POWER SUPPLY? ?
• 100-240V AC, 50/60Hz? ?
• On/Off Power switch? ?
• Power Consumption: 30 watts? ? RIGGING? ?
• Split Yoke Design / Hanging or Floor
• Mounting bracket and safety I-hook installed ?
• Optional bracket kit for multiple units (DLEDKIT)? ?
DIMENSIONS & WEIGHT:? ?
• 16.3”L x 4.5”W x 3.2”H? ?
• 5 lbs. (7.7lbs packaged)
• USITT-DMX 512? ?
• 3, 4, 12 OR 15CH operation modes? ?
• LED Menu Display control 4 button
• Built in color macros / chases
• Stand alone or Primary/Secondary function
• Pixel control in 12 or 15 ch mode? ?
• 3 & 5 pin XLR in/out? ?
• IEC Power in/out? ? CONTROL FEATURES? ?
• Primary/Secondary auto program and music trigger ? ?
• 8 built-in programs with Speed control? ?
• Strobe effect (0-18 flashed per second)? ?
• Control each L.E.D. independently? ?
• 0-100% Dimming? ? POWER SUPPLY? ?
• 100-240V AC, 50/60Hz? ?
• On/Off Power switch? ?
• Power Consumption: 30 watts? ? RIGGING? ?
• Split Yoke Design / Hanging or Floor
• Mounting bracket and safety I-hook installed ?
• Optional bracket kit for multiple units (DLEDKIT)? ?
DIMENSIONS & WEIGHT:? ?
• 16.3”L x 4.5”W x 3.2”H? ?
• 5 lbs. (7.7lbs packaged)
