OPTO BRANCH 4
OPTO BRANCH 4SKU# OPTO BRANCH 4
The OPTO BRANCH 4™ is a single rack space, 4-way distributor/booster with 3pin and 5pin XLR input and output jacks. This unit takes the incoming DMX signal and splits it to four (4) separate outputs that are electronically isolated from each other to ensure uninterrupted data. In addition, each output has dedicated drivers to boost the incoming signal, and the unit includes a link / terminate button for easy troubleshooting.
Link / Terminate Button for Easy Troubleshooting
DMX Status LED Indicator
(1) 3pin + (1) 5pin Neutrik XLR Isolated Inputs
(1) 3pin + (1) 5pin Neutrik XLR Passive Loop Output
(4) 3pin + (4) 5pin Neutrik XLR Isolated Outputs
19” (482mm) x 5.7” (145mm) x 1.7” (44mm)
5.3 lbs. (2.4kg)
AC 120V - 60Hz
PRO CABLES (click for more info)
Specifications and documentation subject to change without notice.
