ARTISTE DAVINCI WH
Artiste DaVinci WH is a professional-grade lighting solution.
Replaced By
Related Products
ARTISTE DAVINCI WH
The Artiste DaVinci WH™ is an all white color exterior housing version of the Artiste DaVinci™ featuring a new 270W LED Cool White LED engine with advanced optics delivering over 12,000 total lumens, ultra wide 6° to 48° zoom, full CMY color mixing and linear CTO color correction, 7 dichroic colors including CTB and Violet, 6 rotating glass and 9 static-stamped metal interchangeable gobos, 3-facet and linear rotating prisms, frost filter, full 360° bi-directional animation wheel, motorized iris, focus, and auto-focus, variable dimming curve modes, high speed electronic shutter and strobe, hibernation mode, DMX, RDM (Remote Device Management), Art-NET, and sACN protocol support, Elation's E-FLY™ internal wireless DMX transceiver, locking 5pin XLR DMX, RJ45 ethernet, power connections, full color 180° reversible menu display with 6 button touch control panel, battery backup for display power, adjustable LED refresh rate and gamma brightness for flicker free operation for TV and FILM, and a multi-voltage universal auto switching power supply (100-240v).
- All White Exterior Housing
- 270W Cool White 12,000 Lumen LED Spot Luminaire
- 6° to 48° Motorized Zoom
- Full CMY Color Mixing and Linear CTO Color Correction
- 7 Dichroic Colors including CTB and Violet
- 6 Rotating and 9 Static-Stamped Interchangeable Gobos
- 3-Facet and Linear Rotating Prisms and Frost Filter
- Full 360° Bi-Directional Animation Wheel
- High Speed Electronic Shutter and Strobe
- Motorized Iris, Focus, and Auto-Focus
- Variable Dimming Curve Modes
- DMX, RDM, Art-NET, and sACN Protocol Support
- Elation's E-FLY™ Internal Wireless DMX Transceiver
- Low Heat, Quiet Operation, Hibernation Mode
- Adjustable LED Refresh Rate Frequency and Gamma
- Flicker Free Operation For Broadcast TV and FILM
Specifications
SOURCE
270W Cool White LED Engine
50,000 Hour Average LED Life*
*Test lab conditions. May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
12,000 Total Lumen Output
CRI 72+
EFFECTS
6° - 48° Motorized Zoom
3-Facet and Linear Rotating Prisms and Prism Macros
Full 360° Bi-Directional Rotating Animation Wheel
Frost Filter Hybrid Wash Effect
Motorized Zoom, Iris, Focus and Auto-Focus
High Speed Electronic Shutter and Strobe
Variable 16-Bit Dimming Curve Modes
Adjustable LED Refresh Rate Frequency and Gamma Brightness
Pan Angle: 540°, 630°
Tilt Angle: 255°
COLOR
7 Dichroic Colors + CTB
Full CMY Color Mixing
Linear CTO Color Correction
GOBOS
2 Gobo Wheels
6 Interchangeable Rotating / Indexing Gobos
9 Interchangeable Static-Stamped Metal Gobos
CONTROL / CONNECTIONS
(3) DMX Channel Modes (40 total channels)
6 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
8 / 16 Bit Resolution Adjustable Movement
DMX, RDM, Art-Net, sACN Protocol Support
Elation's E-FLY™ Internal Wireless DMX Transceiver
Locking 5pin XLR DMX, RJ45 Ethernet, and Power
With Wired Digital Communication Network
SIZE / WEIGHT
Length: 16.4" (416mm)
Width: 11..2" (284mm)
Vertical Height: 25.4" (645mm)
Weight: 56.0 lbs. (25.4kg)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
470W Max Power Consumption
14°F to 113°F (-10°C to 45°C)
FIRMWARE UPDATES
Current Version: V1.2.8
Click HERE for software updates
Specifications and documentation subject to change without notice.
