DESIGN LED 12 BRICK
Discontinued
Design LED 12 Brick is a professional-grade lighting solution. (rated at 100,000 Hours) • Built-in Power Supply and DMX 512 Control.
DESIGN LED 12 BRICK
Sale price$0.00
DESIGN LED 12 BRICK
HIGH OUTPUT LED COLOR CHANGER FEATURES 12 x 1W Luxeon LED's - (4 Ea. R, G, B) Seamless RGB color mixing Infinite Color possibilities Compact Design 44° Beam Angle 480 lumens @ 1m per unit 1340 lumens @ 1m per kit of 4 units Long Life L.E.D. (rated at 100,000 Hours) Built-in Power Supply and DMX 512 Control
Specifications
CONTROL SPECIFICATIONS
• USITT-DMX 512
• 6, 12 OR 15CH operation modes
• 12 Position Binary dip switches
• 3 amp; 5 pin XLR in/out
• IEC Power in/out
CONTROL FEATURES
• Primary/Secondary auto program and music trigger
• 8 built-in programs with Speed control
• Strobe effect (1-18 flashed per second)
• Control each L.E.D. independently
• 0-100% Dimming
POWER SUPPLY
• 90-250V AC, 50/60Hz
• On/Off Power switch
• Power Consumption: 30 watts
RIGGING
• Mounting bracket and safety I-hook installed
• Optional bracket kit for multiple units (DLEDKIT)
DIMENSIONS amp; WEIGHT:
• 13”L x 3”W x 4.5”H
• 4.5 lbs.
• USITT-DMX 512
• 6, 12 OR 15CH operation modes
• 12 Position Binary dip switches
• 3 amp; 5 pin XLR in/out
• IEC Power in/out
CONTROL FEATURES
• Primary/Secondary auto program and music trigger
• 8 built-in programs with Speed control
• Strobe effect (1-18 flashed per second)
• Control each L.E.D. independently
• 0-100% Dimming
POWER SUPPLY
• 90-250V AC, 50/60Hz
• On/Off Power switch
• Power Consumption: 30 watts
RIGGING
• Mounting bracket and safety I-hook installed
• Optional bracket kit for multiple units (DLEDKIT)
DIMENSIONS amp; WEIGHT:
• 13”L x 3”W x 4.5”H
• 4.5 lbs.
