Magma Fan Tour
The Magmatic Magma Fan Tour is a high-output, IP65-rated professional wind machine designed for touring and outdoor productions. With powerful airflow, DMX and optional battery operation, it delivers reliable, controllable wind effects in any environment.
Magma Fan Tour
Sale price$0.00
Magma Fan Tour
The Magma Fan Tour is a rugged, professional-grade wind machine engineered for touring, outdoor events, and permanent installations where reliability and control are critical. Capable of producing up to 5,400 m³/h of airflow with wind speeds reaching 78 km/h, it delivers powerful and consistent wind effects suitable for haze dispersion, scenic effects, and atmospheric control.
Designed with versatility in mind, the Magma Fan Tour features adjustable fan speeds, DMX control, and RDM support for seamless integration into modern lighting and FX systems. Stand-alone operation with a waterproof touchscreen interface allows quick configuration directly on the unit, while remote control and manual speed adjustment provide additional flexibility.
Built for demanding environments, the IP65-rated housing protects against dust and water, making it ideal for outdoor stages and touring applications. With a durable obsidian gray enclosure, integrated handle, and efficient air-cooled design, the Magma Fan Tour is a dependable solution for professional productions requiring controlled, high-powered wind effects.
Specifications
Effect
- Maximum Fan Volume: 5,400 m³/h (≈ 3,180 CFM)
- Average Wind Speed (before net protection): 78 km/h (48.5 mph)
- Fan Speed Range: 1,500–3,600 rpm
- Fan Speed Adjustment: Yes
- Motor Power: 0.612 HP
- Wind Direction Angle: 36°
Control
- DMX Channels: 2
- DMX Modes: 1
- DMX Connectors: 5-pin
- RDM: Yes
- Stand-Alone Operation: Yes
- Onboard Control: On/Off, Fan Speed, DMX Address Setting, Battery Status
- Remote Controller Connection: 4-pin XLR
- Display: Waterproof touchscreen
- Manual Speed Control: Yes
- External Battery Support: Yes
Power
- Input Voltage: 100–240V
- Frequency: 50/60 Hz
- Power Consumption: 450 W
- Maximum Starting Power: 550 W
- Outdoor, IP65, power locking power input
Fixture
- IP Rating: IP65
- Cooling: Air cooled
- Max Ambient Temperature: 40°C (104°F)
- Surface Temperature: 40°C (104°F)
- Handle: Yes
- Fan Material: Plastic
- Housing Color: Obsidian gray
Dimensions Weight:
- Dimensions (L × W × H): 20.1 × 18.0 × 22.1 in (510 × 456.5 × 562 mm)
Weight:
- 34.8 lbs (15.8 kg)
Specifications are subject to change without notice.
