PIXEL TAPE 16IP


PIXEL TAPE 16IP is a professional-grade lighting solution. The PIXEL TAPE 16IP ™ is an IP65, outdoor rated, 8.9 foot (2.7m) flexible LED pixel tape featuring (170) RGB SMD tri-color LED pixels (510 total DMX channels), producing over 1 billion color possibilities with a 120° viewing angle and is surface coated with an IP65 rated conformal coating. PIXEL TAPE 16IP can be powered and controlled using our PIXEL DRIVER 170, PIXEL DRIVER 1000IP or PIXEL DRIVER 4000 V2 control drivers.

UPC: 810008262740SKU: PIX618

PIXEL TAPE 16IP

The PIXEL TAPE 16IP™ is an IP65, outdoor rated, 8.9 foot (2.7m) flexible LED pixel tape featuring (170) RGB SMD tri-color LED pixels (510 total DMX channels), producing over 1 billion color possibilities with a 120° viewing angle and is surface coated with an IP65 rated conformal coating. PIXEL TAPE 16IP can be powered and controlled using our PIXEL DRIVER 170, PIXEL DRIVER 1000IP or PIXEL DRIVER 4000 V2 control drivers.

  • IP65 Outdoor Rated Flexible LED Pixel Tape
  • 8.9 foot (2.7m) Roll
  • (170) RGB Tri-Color SMD LED Pixels
  • (510) Total DMX Channels
  • Pixels Spaced on 0.62"(16mm) Centers
  • Cut Every 0.98"(25mm)
  • 120° Viewing Angle
  • 455 Lumens
  • Over 1 Billion Color Possibilities

Specifications

SOURCE:
(170 Pieces) APA102 / RGB

LED SPACING:
16mm Pixel Pitch

PHOTOMETRIC OUTPUT:
455 Lumens

COLOR:
Over 1 Billion Color Possibilities

CONTROL:
(510) DMX Channels
ICS APA102 Protocol

SIZE / WEIGHT:
Length: 107.2" (2,720mm) Roll
Width: 0.5” (12mm)
Vertical Height: 0.1" (3mm)
Weight: Under 1 lb. (0.2kg)

ELECTRICAL / THERMAL:
DC 24V
35W Max Power Consumption

APPROVALS / RATINGS:
CE
cETLus (PENDING)
IP65

Specifications and documentation subject to change without notice.
