PRISMA WASH 100

Name: PRISMA WASH 100
Brand: Elation
SKU: PSW300
Availability: InStock

38x 2W 365nm LED IP65 100° Wash Fixture

PRISMA WASH 100 is a professional-grade lighting solution. PRISMA WASH 100™ is an exterior IP65 rated UV wash luminaire that produces 365nm peak true UV output with zero visible light. Features include a scoop LED reflector design which creates an impressive 90 degree wide beam angle, manual adjustable tilt positioning and versatile rigging options, a user friendly digital 2.5 inch LCD touch screen control panel, intuitive DMX-512 and RDM control, and IP rated power and data in/out.

UPC: 810008261040

SKU: PSW300

Related Products

PRISMA WASH 25

PRISMA WASH 100

PRISMA WASH 100™ is an exterior IP65 rated UV wash luminaire that produces 365nm peak true UV output with zero visible light. Features include a scoop LED reflector design which creates an impressive 90 degree wide beam angle, manual adjustable tilt positioning and versatile rigging options, a user friendly digital 2.5 inch LCD touch screen control panel, intuitive DMX-512 and RDM control, and IP rated power and data in/out.

Optional accessories include a Black Glass diffusion filter to create a complete blackout effect, only allowing UV rays to penetrate, and extended length IP rated power and data linking cables.

IP65 Rated Exterior High-Power UV Wash Luminaire

Scoop LED Reflector Design

90 Degree Wide Beam Angle

365nm Peak True UV Wavelength

Zero Visible Light Output

Optional Black Glass Diffusion Filter

Specifications

SOURCE

(38) 2W High Power UV Diode LEDs
20,000 Hour Average LED Life*

_{*Test lab conditions. May vary depending on several factors including but not limited to:}

_{Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.}

PHOTOMETRIC DATA

90 Degree Wide Beam Angle

365nm True UV Peak Wavelength

EFFECTS

High Speed Electronic Strobe

Variable Dimming Curve Modes

CONSTRUCTION

Rugged IP65 Rated Aluminum Housing

Manual Adjustable Tilt Position

CONTROL

Multiple DMX Channel Modes

Onboard 4 Button Touch Control Panel

DMX-512 and RDM Protocol Support

CONNECTIONS

Locking 5pin XLR Connector In/Out

IP65 Locking Power Connector In

With Wired Digital Communication Network

SIZE / WEIGHT

Length: 17.24” (438mm)

Width: 5.82” (148mm)

Vertical Height: 11.29” (287mm)

Weight: 18.5 lbs. (8.4 kg)

ELECTRICAL

AC100-240V 50-60Hz

T2A/250V

83W Max Power Consumption

THERMAL

Ambient Temperature (Ta max) 104°F (40°C)

Air Cooled

APPROVALS / RATINGS

CE | cETLus | IP65

Specifications and documentation subject to change without notice.
