SŌL IV BLINDER
4x 350W RGBLAW LED Blinder IP65
SŌL IV BLINDER is a professional-grade lighting solution. Introducing the SŌL IV BLINDER , the most versatile addition to the SŌL Series yet, featuring a grid of four fixtures in a single modular housing. Like the SŌL I and SŌL II, the SŌL IV offers the same cutting-edge technology and powerful LED engine but with even greater creative potential through its multi-fixture design. This flexibility allows lighting professionals to craft expansive arrays, intricate shapes, and dynamic effects that adapt to any stage or event setup.
SŌL IV BLINDER
Introducing the SŌL IV BLINDER, the most versatile addition to the SŌL Series yet, featuring a grid of four fixtures in a single modular housing. Like the SŌL I and SŌL II, the SŌL IV offers the same cutting-edge technology and powerful LED engine but with even greater creative potential through its multi-fixture design.
The SŌL IV BLINDER can be used as a standalone fixture or interconnected in endless configurations with additional SŌL IV units, as well as the SŌL I and SŌL II models. This flexibility allows lighting professionals to craft expansive arrays, intricate shapes, and dynamic effects that adapt to any stage or event setup.
With the same 350W RGB+Lime+Amber+White LED engine, 93+ CRI, and IP65-rated durability, the SŌL IV delivers unmatched brightness, color fidelity, and performance. Whether you're looking for an impactful standalone solution or a fixture that integrates seamlessly into a larger lighting design, the SŌL IV BLINDER provides the ultimate canvas for your creativity.
Illuminate your vision with the boundless possibilities of the SŌL IV BLINDER "“ the next step in redefining stage lighting innovation.
- 4x 350W RGBLAW LED
- 59,830 Total Fixture Lumen Output (Sphere)
- 46° Beam Angle
- Simple 'Array Mode' Addressing System
- Individual Pan Adjustment with Lock
- Dim-to-Warm/ Red Shift Emulation
- High Output Blinder Mode or Constant Output Mode Options
- Unique Horizonal and Vertical Array Rigging Method (Compatible with SŌL II, SŌL I Blinder Frame, Pulse Panel, SIX+ BAR and PULSE BAR)
- IP65 Rated
Specifications
4x 350W RGBLAW LED
30,000 Hour Average LED Life*
*May vary depending on several factors including but not limited to:Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.
PHOTOMETRIC DATA
Total Lumen Output:
59,830 (Integrating Sphere)
CRI TBA
Compound Lens
Beam Angle: 46°
Field Angle: 85°
No Lens
Beam Angle: 52°
Field Angle: 95°
EFFECTS
Variable Strobe Rate: 1- 20Hz
Dim-to-Warm/ Red Shift Emulation
Variable 16-bit Dimming Modes and Curves
High Output Blinder Mode or Constant Output Mode Options
COLOR
RGBLAW Color Array
CMY Emulation
Variable CCT 1800K - 8500K
Virtual Gel Swatch Book
CONTROL / CONNECTIONS
24 DMX Channel Modes (1ch, 2ch, 4ch, 2ch, 4ch, 8ch, 3ch, 5ch, 9ch, 4ch, 8ch, 16ch, 6ch, 12ch, 24ch, 7ch, 10ch, 16ch, 40ch, 69ch, 28ch, 45ch, 28ch 45ch)
Simple 'Array Mode' Addressing System
Manual and DMX Controlled Dimmer and Color
4 Button Control Panel, LED Display
Aria x2 Wireless Device Management
RDM (Remote Device Management)
IP65 5pin DMX Cable In/Out
IP65 Locking Power Cable In
SIZE / WEIGHT (Without Accessories)
Length: 9.4" (240mm)
Width: 16.5” (420mm)
Vertical Height: 18.6” (471mm)
Weight (Fixture Only): 41.9 lbs (19.0 kg)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
1300W Max Power Consumption
5°F to 113°F (-15°C to 45°C)
BTU/hr (+/- 10%) 4262.5
INCLUDED ITEMS
Removable Fixture Yoke / Omega Bracket
2x Fixture Interconnect splices
Safety Cable
IP65 Locking Power Cable
OPTIONAL ITEMS
SŌL IV HD Yoke (SŌL4HDY)
SŌL Fresnel Lens (SŌLFL)
SŌL Frosted Lens (SŌLFRO)
SŌL Bowens Adapter (SŌLBA)
SŌL Dome Lens (SŌLDL)
SŌL Blackout Lens (SŌLBL)
SŌL Gel Frame Holder Kit (SŌLGFHK)
SŌL Barndoor (SŌLBD)
Fixture Interconnect splice 6 Pack (FISP06)
Interconnect Clamp Adapter (FICA01)
# 8050000053 - Omega Bracket
APPROVALS / RATINGS
CE | IP65 | FCC | UKCA
FIRMWARE UPDATE
Current Update:
Specifications and documentation subject to change without notice.
